Page 15
(3) To set the right limit of the travel envelope, run the monitor right
until it has reached the desired position. Quickly press and release the
Red Programming Button. The status LED will flash rapidly
approximately 8-10 times to acknowledge the new travel limit position as
well as the completion of the programming sequence.
(4) Replace the RF Receiver/Control Module cover removed earlier.
Caution:
Left/Right rotation travel envelope should be verified to be correct after
programming. If the monitor does not stop at the programmed rotational limit positions then
re-program the rotational limits. Checking rotational limits should be part of normal truck
maintenance.
Caution:
Using the left-right override nut when the power to the receiver module is off or the horizontal
motor is disconnected will move the horizontal limits from their original programmed
positions.
