30
SYSTEM SPECIFICATIONS
7100 EXM Monitor
 Max Flow Rating 700 GPM (2650 LPM)
 Max Operating Pressure 500 PSI Limited Duty (34.5 BAR)
 Inlet Size 2.5” NPT
 Outlet Size 2.5” NHT
 Travel V: -45° to +90°
H: L175° to R175°
 Movement Sealed Electric Motors
 Weight 19 Lbs.
 Operating temperature range -40°F to +185°F (-40°C to +85°C)
 Environmental Rating NEMA 4
Monitor Controller
 Input power 12/24 VDC (11 VDC to 27 VDC)
 Control Communication CAN bus J1939
2.4 Ghz digital radio frequency (unlicensed)
 Electrical Load See Table 1 Below
 Fuse Rating 40 AMPS (12V) & 20 AMPS (24V)
 RF power output Meets FCC part 15 requirements for license free operation
 Operating temperature range -40°F to +185°F (-40°C to +85°C)
 Environmental Rating NEMA 4
 FCC ID KQL-2510100
Motor Left/Right Up/Down Nozzle
Run Current 5 A 5 A 0.5 A
Stall Current 70 A 70 A NA
Current Trip Point 20 A 20 A 4 A
Table 1: Motor Current Specifications
Panel Mount Controller - 7010
 Input power 12/24 VDC (11 VDC to 27 VDC)
 Electrical Load 0.5 AMPS
 Fuse Rating 1 AMPS (12V) & 0.5 AMPS (24V)
 RF power output Meets FCC part 15 requirements for license free operation
(Output if applicable)
 Transmitter dimensions 7 17/32” x 3 19/32” X 1 1/8”
 Transmitter weight 0.815 lbs.
 Operating temperature range -40°F to +185°F (-40°C to +85°C)
 Environmental Rating NEMA 4
 FCC ID KQL-2510100
