Elkhart Brass Sidewinder 8494 Monitor User Manual
Page 27
23
8494 SIDEWINDER MONITOR PART LIST
IND.#
PART #
QTY
PART DESCRIPTION
1 17908001
1 MONITOR
OUTLET
BODY
2
15027000
144
BALLS-0.250 DIA. SS (36 PER RACE)
3
57502000
2
O-RING AS 568-148F (2.737 ID X 0.103 C/S)
4
63687000
5
SET SCREW 0.312-18 X 0.187 LG BLK NYLON
5
31011000
2
GREASE FITTING (SS)
6
51248000
2
ROLL PIN 0.125 DIA. X 0.625 LG SS
7 47652001
2 OVER-RIDE
NUT
8
65140000
1
SCREWS #6-32 X 0.750 LG SOC BTN HD SS
9
23572000
1
CLAMP LOOP (NYLON) 0.140 HOLE
10
65139000
3
SCREWS #6-32 X 0.625 LG SOC BTN HD SS
11
71176000
3
WASHER - #6 SS
12 65572000 4 SPACER
-
SENSOR
13 65104000 2 POSITION
SENSOR
14
18219001
1
MONITOR INLET BODY
15
44339000
1
SERIAL NO./IDENTIFICATION PLATE
16
61215100
4
DRIVE SCREW #4 X 0.187 RND HD SS
17
17975001
1
MONITOR BASE (2.0 NPT FEMALE)
18
64072000
8
CAP SCREWS #10-32 X 0.500 LG SOC HD SS
19
81119001
2
MOTOR ASSY (12 VDC SLOW)
19
81147001
2
MOTOR ASSY (12 VDC FAST)
19
81207001
2
MOTOR ASSY (24 VDC SLOW)
19
81240001
2
MOTOR ASSY (24 VDC FAST)
20
36791200
1
QUICK CONNECT HARNESS EXTENSION
21
63797000
1
SCREW #10-32 X 0.250 LG SLT PAN HD SS
22
23570000
1
CLAMP LOOP CUSHIONED
23
36833100
1
MONITOR CONTROL HARNESS
24
23571000
2
CLAMP LOOP (NYLON) 0.210 HOLE
25
71515000
4
THRUST WASHER 1/4
26 17701000 2 THRUST
BEARING
1/4
27
65201000
2
SET SCREW #10-32 X 0.125 LG SOC HD SS
28 20991001 2 COUPLING
29
65219000
2
SET SCREW #10-32 X 0.187 LG SOC HD SS
30
51071000
2
SOLID PIN (DRIVE LOCK E) 0.125 DIA X 0.875LG
31
63935001
2
WORM SHAFT SS
32 63601001 2 SPACER
33
71516000
4
THRUST WASHER 5/16
34 17702000 2 THRUST
BEARING
5/16
35
57380000
2
O-RING AS 568-008 (0.176 ID X 0.070 C/S)
36 46054000 4 MAGNETS
OPTIONAL QUICK CONNET CPLG ASSY
37 81342001 1 QUICK
CONNECT
COUPLING
OPTIONAL FOR USE WITH P/N 81342001 QUICK CONNECT ADAPTER
38
81342051
1
DUST PLUG ASSY WITH CHAIN
