10
4. 81181001 Water Valve Kit (Optional)
The 81181001 Valve Kit is for use with 12V DC systems ONLY. To use the valve kit with a 24V
system an 81298001 Water Valve Kit (24V) should be used.
Warning:
Using the 81181001 Water Valve Kit on a 24VDC system will damage the position sensors and burn
out the motor. Elkhart Brass P/N 81298001 Water Valve Kit (24V) is the 24V replacement for the
81181001 Water Valve Kit.
Install the valve inline with the monitor. Mount the 81196000 or 81294001 control
module to the apparatus. The cables should be routed away from any heat sources, and be protected
from sharp corners. They should be tied down securely to prevent fretting or fraying due to vehicular
vibrations. Several optional cable lengths are available for the valve controller to allow it to be
mounted in a convenient location. Connect the motor power and sensor lead to the valve harness. See
Section III.B. Optional Valve Controller Specifications. Wire an inline fuse to the positive (red) lead
of the control module (the same fuse that was used for the 81713000 can be used here). Connect the
control connector to the free connector on the control harness.
Part No. Length
36779100 1ft
36779200 3ft
36779300 5ft
36779400 8ft
36779500 10ft
36779800 25ft
Control Harness to Valve Module
Extension Cables
