Section 2 - Pre-Operation And Inspection
2-10
31200114
2.6
WINDOWS
Keep all windows and mirrors clean and unobstructed.
Cab Door Window
• During operation the window must either be latched open or closed.
• Open the cab door window (1) and secure it in the latch.
• Press the release button (2) inside the cab to unlatch the window.
Rear Window
• Lift lever (3) and push to open the rear window (4).
• Lift lever and pull to close.
OZ0210
1 2
3
4
OZ0220
