Section 5 - Attachments and Hitches
5-25 31200114
To open/close grapple:
Use the button (3) to select the auxiliary hydraulic circuit.
Press joystick button (4) to close grapple or press joystick button (5) to open
grapple.
OR
While pressing and holding the joystick button (6), move the joystick forward to close
grapple or move the joystick back to open grapple.
Installation Procedure:
• Refer to “Attachment Installation” on page 5-7.
Equipment Damage Precautions
• Do not use bale handler as a lever to pry material. Excessive prying forces could
damage the bale handler.
Operation:
• Travel in accordance with requirements set forth in Section 1 - General Safety
Practices.
OAH1150
3
4
5
6
