Det-Tronics X2200 UV Flame Detector - Manual (Page 23)

21 95-8549 13.1
REspONsE ChARACTERIsTICs
Very high sensitivity
Fuel size
Distance
feet (m)
Typical Response Time
(seconds)*
Mode
n-Heptane 1 x 1 foot 85 (25.9) 3 Low Arc
Methane 32 inch plume 100 (30.5) 2 Low Arc
FM Approval and performance Report – Continued
Medium sensitivity
Fuel size
Distance
feet (m)
Typical Response Time
(seconds)*
Mode
n-Heptane 1 x 1 foot 35 (10.6) 2 Standard
n-Heptane 1 x 1 foot 50 (15.2) 3 Hi Arc
Methane 1 x 1 foot 55 (16.8) 2 Standard
Methane 32 inch plume 55 (16.8) 2 Hi Arc
*Add 2 seconds for EQP model.
REspONsE ChARACTERIsTICs IN ThE pREsENCE OF FALsE ALARM sOuRCEs
Very high sensitivity (standard Mode)
False Alarm source
Distance
feet (m)
Fire source
Distance
feet (m)
Typical
Response Time
(seconds)*
Sunlight, direct, modulated, reflected — 6-inch propane 10 (3) <30
6 kw heater, modulated & unmodulated 10 (3) 1 x 1 foot n-Heptane 75 (22.9) 1
250 w vapor lamp, modulated & unmodulated 3 (0.9) 1 x 1 foot n-Heptane 75 (22.9) 1
300 w incandescent lamp, modulated & unmodulated 3 (0.9) 1 x 1 foot n-Heptane 75 (22.9) 1
1500 w electric radiant heater, modulated & unmodulated 10 (3) 1 x 1 foot n-Heptane 75 (22.9) 1
2-34 w fluorescent lamps, modulated & unmodulated 3 (0.9) 1 x 1 foot n-Heptane 75 (22.9) 1
*Add 2 seconds for EQP model.
FALsE ALARM IMMuNITy
Very high sensitivity (standard Mode)
False Alarm source
Distance
feet (m)
Modulated Response unmodulated Response
Sunlight, direct, modulated, reflected — No Alarm No Alarm
Vibration N/A No Alarm No Alarm
6 kw heater 3 (0.9) No Alarm No Alarm
250 w vapor lamp 3 (0.9) No Alarm No Alarm
300 w incandescent lamp 3 (0.9) No Alarm No Alarm
1500 w electric radiant heater 3 (0.9) No Alarm No Alarm
2-34 w fluorescent lamps 3 (0.9) No Alarm No Alarm
high sensitivity
Fuel size
Distance
feet (m)
Typical Response Time
(seconds)
Mode
n-Heptane 1 x 1 foot 60 (18.3) 2 Standard
n-Heptane 1 x 1 foot 60 (18.3) 2 Hi Arc
n-Heptane 1 x 1 foot 60 (18.3) 7 Very Hi Arc
Methane 32 inch plume 70 (21.3 2 Standard
Methane 32 inch plume 70 (21.3 2 Hi Arc
Methane 32 inch plume 70 (21.3 2 Very Hi Arc
