CERTIFICATIoN AND FAILURE RATE DATA
All Safety-Certified FlexSonic Acoustic Detectors are
certified compliant to:
IEC61508: 2010
Type B Element
Systematic Capability: SIL 2 certified
HFT: 0
Low Demand Mode
PFDavg should be calculated for any safety instrumented
function using the FlexSonic Acoustic Detector. (Refer
to FMEDA report for necessary information, including
DU rate.)
Safety Accuracy:
±10% of applied acoustic leak
pressure.
Safety Response Time: Refer to the FlexSonic
Acoustic Detector instruction
manual for details.
Product Life:
10 years, based on
manufacturer data.
All failure rate data for SIL verification is in the FMEDA
report, which is available upon request.
ADDITIoNAL CERTIFICATIoNS
FM, CSA, ATEX, IECEx, CE, and others.
Refer to the FlexSonic Acoustic Detector Instruction
Manual for details.
For complete information regarding performance,
installation, operation, maintenance and specifications
of the FlexSonic Acoustic Detector, refer to instruction
manual 95-8657.
TERMS AND DEFINITIoNS
AMS
Asset Management System
FMEDA
Failure Mode Effects and Diagnostics
Analysis
HART
Highway Addressable Remote
Transducer
HFT
Hardware Fault Tolerance
PFD
Probability of Failure on Demand
(Probability of Dangerous Failure)
PFDavg
Average Probability of Failure on
Demand
SFF
Safe Failure Fraction
SIF
Safety Instrumented Function
SIL
Safety Integrity Level
SIS
Safety Instrumented System
AC100
Acoustic Sensor (contains microphone,
AIC acoustic source, and associated
circuitry)
ATX10
Transmitter for acoustic spectrum
analysis and control functions
Acoustic
Detector
Consists of one Model AC100 Sensor
and one Model ATX10 Transmitter
UD10 FlexVu
®
Model UD10 Universal Display
Detector Electronics Corporation
6901 West 110th Street • Minneapolis, Minnesota 55438 USA
Operator: (952) 941-5665 or (800) 765-FIRE
Customer Service: (952) 946-6491 • Fax (952) 829-8750
http://www.det-tronics.com • E-mail: [email protected]
Specifications subject to change without notice.
Det-Tronics and FlexSonic are registered trademarks or trademarks of
Detector Electronics Corporation in the United States, other countries, or both.
Other company, product, or service names may be trademarks or service
marks of others.
©Copyright Detector Electronics Corporation 2013. All rights reserved.
R
EG
IST
ERE
D BY UL AN
D B
SI
NO
. A2305 • NO. 2582
6
ISO 9001
RE
GIS
TERED FIRM
R
EG
IS
TERED FIR
M
Failure Category
l
sd
l
su
2
l
dd
l
du
SFF
3
Acoustic Detector Analog Output (consists of one Model
AC100 Sensor and one Model ATX10 Transmitter)
0
125
1925
97
95.5
IEC 61508 Failure Rates in FIT
1
1
FIT = 1 Failure / 10
9
Hours
2
It is important to realize that the No Effect failures are no longer included in the Safe Undetected failure category according to IEC 61508,
ed2, 2010.
3
Safe Failure Fraction needs to be calculated on (sub)system level.
