4.4. MRC5000 Setup (Optional)

Refer to instructions provided recorder manufacturer for more
specific installation notes.
Temperature is retransmitted to the MRC5000 recorder from the controller. Set up the recorder
by:
1. Ensure hardware jumper JU1 is in place for the 5 VDC setting (Refer to MRC5000 Manual
included).
2. Move Mode to PROG/TEST/CAL to display Prog .
3. Press ▼ twice to display Inps . Move to each Parameter Code using ▼or ▲. Adjust each
Parameter Code using the settings in Table 5.
4. After adjusting all settings, move Mode to RUN . Display on both the Recorder and controller
should read the same.
Table 5. MRC 5000 Settings.
Parameter Code
Degrees C Degrees F
Inps 18 18
Icor 0 0
diSP On On
dPOS 0 0
EUU** 400 752
EUL** 0 32
ChUP 400 800*
ChLO 0 0
DFF 1 1
* Change 0-400 chart paper to 0-800 chart paper. Depending on the equipment used, 0-600
paper may be used if the maximum temperature is 500°F.
** These values must match the settings sRetOutLo and RetOutHi on the Protocol 3 Control
page. For example, if RetOutLo is 32, EUL must read 32.
