PX-7 DL Ultrasonic Thickness Gauge
1
INTRODUCTION
The Dakota Ultrasonics model PX-7 DL is a precision Ultrasonic
Micrometer. Based on the same operating principles as SONAR, the PX-7
DL is capable of measuring the thickness of various materials with
accuracy as high as
±
0.0001 inches, or
±
0.001 millimeters. The principle
advantage of ultrasonic measurement over traditional methods is that
ultrasonic measurements can be performed with access to only one side of
the material being measured.
This manual is presented in three sections. The f irst section covers
operation of the PX-7 DL, and explains the keypad controls and display.
The second section provides guidelines in selecting a transducer for a
specific application. The last section provides application notes and a table
of sound velocity values for various materials.
Dakota Ultrasonics maintains a customer support resource in order to
assist users with questions or difficulties not covered in this manual.
Customer support may be reached at any of the following:
•
Dakota Ultrasonics, 1500 Green Hills Road, #107
Scotts Valley, CA 95066 USA
•
Telephone: (831) 431-9722
•
Facsimile: (831) 431-9723
•
www.dakotaultrasonics.com
