PX-7 DL Ultrasonic Thickness Gauge
23
Using the Data Logger (con't)
•
The current file will be diplayed ( F-01, F-03, etc. )
4) Press the UP / DOWN arrow keys to scroll to the file ( 1-10 ) that
will be used to record the measurements.
5) Press the SEND key once again to select the file.
•
Note: The display will flash the FILE / F-04 ( The selected file
)symbol.
6) Press the MEM key, once again, to advance to the storage
locations in the file selected.
•
Note: The display will flash the current storage location ( L007,
L039, etc. ), followed by the status of the location. The storage
location can contain one of three possible things: a) a
measurement that was previously stored. b) A clear location,
indicated by the CLr symbol. c) Obstruct ( ObSt ), indicating that a
measurement could not be obtained.
7) Press the UP / DOWN arrow keys to advance to the desired cell
location.
8) Take a measurement and press the SEND key to store a reading in
the desired location.
•
The data logger will automatically advance to the next storage
location in sequential order.
9) Repeat step 8 as required.
