Condux Hand Held Micro Fiber Optic Blower - Manual (Page 16)

16
Item No. Part_Number Dwg_Description Quantity
1 00263400 QUAD-RING, 3.5MM-CS CORD 3.53" 2
2 02020000 FTG,HYD 08-NPT_M ;08-NPT_M 1
3 02129700 UNIVERSAL CPLG, 1/2 MALE 1
4 02272600 FTG,HYD 08 O-RING;08-JIC 90 1
5 02288582 GAUGE,PRESS 0-200 1.50 BACK MT 1
6 02288665 NUT M06-1.00 NYLOC ST GR2 CZ 1
7 02288694 NUT M08-1.25 NYLOC ST GR2 CZ 1
8 02289293 BOLT,SWING M10-1.5 X 100 ST 1
9 02289294 SCREW,SHOULDER M10 DIA-40MM 1
10 02289295 SCREW,SHOULDER M08 DIA-70MM 1
11 02289297 CAPSRW M06-1.0X 12 CSSS 18-8 4
12 02289382 NUT M10-1.50 NYLOC STGR2 THNCZ 1
13 08764001 COUPLING,LOWER HALF BLOWER 2
14 08764003 INSERT,LOWER INTERFACE BLOWER 1
15 08764004 INSERT,UPPER INTERFACE BLOWER 1
16 08764006 HANDLE,BALL 4.50 OD-M10 THRDS 1
17 11274400 VALVE,BALL- .50 IN 1
Handheld Blower Assembly
