Prepare Cable/Microcable
The Handheld Blower can be used to install traditional fiber cable or Micro Fiber
Cable. Follow the steps below for the type of cable you will be installing.
Prepare Traditional Fiber Cable:
1. Choose the correct Cable Grip and install on the fiber optic cable (See
Figure 19).
2. Install 5/8” (16 mm) Swivel on Cable Grip using a 3/32” hex wrench.
Grip must be firmly secured to cable (See Figure 20). The eye on the grip
can be compressed to fit smaller diameter conduits. The eye of a new grip
can be taped with electrical tape in order to make it narrower and travel
more easily through the conduit.
3. Chose the correct Carrier and install on Swivel (See Figure 21)
4. Add lubricant to Conduit before Carrier: ¼ of the recommended
amount.
5. Push
Cable Assembly, including entire cable grip, into conduit.
6. Add the rest of the lubricant to the Conduit behind the Cable Assembly.
Figure 19 Installing Cable Grip
Figure 20 Installing Swivel
Figure 21 Install carrier
