ΒΤ 100 USB Bluetooth Dongle Manual

________________________________________________________________________

BlueSoleil offers three security levels:

• Low (Security Mode 1, No security)
No security procedure is needed for connections

• Medium (Security Mode 2, Service level enforced security)
Authentication or Authorization is requested when a specific service is accessed by

other Bluetooth enabled devices. If two devices are connecting for the first time, or if

two devices do not have a trusted relationship, then the same passkey must be

provided on both sides to complete the Authentication. This mode allows you to

assign different access rights for each service supported by the server device.

• High (Security Mode 3, Link level enforced security)
If either of two devices is in Mode 3, Authentication is requested whenever a link

connection is initiated between two Bluetooth enabled devices. The passkey must be

provided on both sides to complete Authentication.

Note:

In Security Mode 2, the user can add each authenticated device into a trusted device

list to expedite future connection.

Pair / Un-pair Devices

Once a device has paired with your computer by exchanging passkeys, passkeys will no

longer be required for further connections between your computer and the remote device.

• How to pair with another device
If a passkey is required for connection, the devices will start the pairing procedure

automatically. If you want to manually pair a device with your computer, go to the

Main Window, right-click on the device icon and select Pair Device.

On both cases the Enter Bluetooth Passkey dialog will appear and you have to enter

the passkey of the remote device.
