Video Features 1 - 15
Quick Start Guide
1
Video Features
Your computer will have EITHER an ATI X700 (ATI M26) PCI Express video card (Model A & B comput-
ers), OR built-in Intel (Intel GMA 900) on-board video (Model C & D computers), depending on your pur-
chase option (see
).
You can switch display devices, and configure display options, from the Display Properties control panel in
Windows as long as the appropriate video driver is installed. For more detailed video information see
eo Driver Controls” on page B - 1
“Intel Video Driver Controls” on page C - 1
To access Display Properties in Windows:
1.
Click Start, point to Settings and click Control Panel (or just click Control Panel).
2.
Double-click Display (icon) - In the Appearances and Themes category.
3.
Click Settings (tab) in the Display Properties dialog box.
4.
Move the slider to the preferred setting in Screen area/resolution
(
Figure 1 - 9 on page 1 - 16
).
5.
Click the arrow, and scroll to the preferred setting In Colors/Color quality
(
Figure 1 - 9 on page 1 - 16
).
6.
You can also access Display Properties by right-clicking the desktop and scrolling down and clicking
Properties. Click Settings (tab) and adjust as above.
7.
Open the Display Properties control panel, and click Advanced (button)
(
Figure 1 - 9 on page 1 - 16
) to
bring up the Advanced properties tabs.
Either
8.
Click through the ATI tabs to make any video adjustments you require for Models A & B computers.
OR
9.
Click the Intel(R) Graphics Media Accelerator Driver tab, and click Graphics Properties (button) to make
any video adjustments you require for Models C & D computers.
