1 - 6 System Map: Top View with LCD Panel Open
Quick Start Guide
1
System Map: Top View with LCD Panel Open
Figure 1 - 2 - Top View with LCD Panel Open
2
5
3
1
7
8
4
1. Optional Built-In PC
Camera
2. LCD
3. LED Power &
Communication
Indicators
4. LED Status Indicators
5. AP-Key Buttons
6. Power Button
7. Keyboard
8. TouchPad and Buttons
9. Speaker
6
9
3
4
5 6
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the module(s) are
OFF if you are using the
computer aboard aircraft.
Use the AP-Key buttons
to toggle power to the
wireless modules, and
check the status indica-
tors to see if the modules
are powered on or not
(see
Table 1 - 3, on
page 1 - 7 ).
