System Map: Left View 1 - 11
Quick Start Guide
1
System Map: Left View
3
1
5 2
4
5
Mini-IEEE 1394 Port
The Mini-IEEE 1394 Port only supports SELF POW-
ERED IEEE 1394 devices.
Figure 1 - 5
Left View
1. RJ-45 LAN Jack
2. S-Video-Out Port
3. External Monitor Port
4. Mini-IEEE 1394 Port
5. 2 * USB 2.0 Ports
External USB Hard Disk Drives
If you are using an external USB HDD (or any USB device with
a power rating of 500mA or above), make sure you use the
power supply which comes with the device.
