ATI Video Driver Controls

B - 10 Display Modes

12. One display will be set to 1 (Primary). The displays may be switched as

long as one as set to Primary.

13. To switch from Extended Desktop mode back to Clone mode, first uncheck

the tick box to disable the Extended Desktop (via the settings tab in the
Display Properties control panel -

Figure B - 5

) and click Apply.

14. Repeat the procedure in

(make sure you have selected the appropriate display to get all the ATI
Mobility Radeon X700 options tabs) to return to Clone mode (click the

button to enable any displays if necessary).

In this picture the notebook
LCD panel is the primary dis-
play, and the desktop may be
extended to any attached dis-
plays.

The primary display is indi-
cated with a

button de-

pressed. Click the buttons

to switch the primary

display.

Figure B - 6

Displays Tab

(Extended Desktop

Mode)
