Carlin 70200 User Manual

Page 2

Carlin part number MN70200 Rev. 02/24/14

Programming and Setup
Definitions

Valve Delay On: Time period motor and ignitor are on prior to Trial for Ignition.

Trial for Ignition (T.F.I.): Burner flame-establishing period. Note: Do not use 45 TFI for burners larger than 3GPH.

Motor Delay Off: Time period the motor is on after the Call for Heat is satisfied to allow for evacuation of combustion gases.

Early Spark Termination: Amount of time prior to the end of TFI when the ignitor is turned off (burner flame must be self supporting).

Flame Stabilize: The time period after TFI that the ignitor remains on (in interrupted ignition mode only).

Ignition Type: Interrupted duty: spark is turned off after a set period; Smart Ignition: If flame is lost at any time after the Trial-for-Ignition period, the

control will recycle (60 - 65 seconds). Following this recycle, the control will operate in Intermittent Duty mode (ignition on throughout the call for heat)
for ten heat cycles. Following these ten cycles, the control will revert back to Interrupted Duty and will remain in Interrupted Duty until another recycle
event occurs.
Smart Ignition: Switches to Interrupted Duty to dramatically extend the life of the ignitor or transformer.

TT Jumpered: Allows TT to be “jumpered” by software program.

Vent Input: Used to verify vent input. When selected, if the vent input is not detected for 5 seconds during motor on time, the control will lockout.

Allowed Recycles: Number of Recycles allowed during a single Call for Heat prior to lockout.

Baseline Reset: Select Yes then push Enter- Resets baseline statistics used by fault history.

Factory Defaults: To reset to factory defaults- select Yes, then push Enter.

Inhibited Features: indicates that feature is inhibited due to other control settings:

• If Motor Delay Off is set to anything other than “0”, then Valve Delay On “0” is inhibited.

• Valve Delay On can only be set to “0” if Motor Delay off is also set to “0”.

• If Early Spark Termination is active (-10, -5), then Flame stabilization and Intermittent ignition type are inhibited.

• If Flame Stabilization is active (+5, +10, +15), then Early Spark Termination and intermittent ignition are inhibited.

• If set for intermittent ignition, early spark termination and Flame Stabilize are inhibited.

Do not start the burner if the combustion chamber contains oil or oil vapor.

Per UL requirements, the control will not turn on if the cad cell senses flame (light) during the self-test. If the cad cell sees flame,

the control will remain in self-test mode until the cad cell no longer senses flame.

To Enter Programming Mode: Simultaneously press and hold the the ▲ + ► buttons for three seconds. The display will show:

To Exit Setup, ESC

for 3 seconds.

To View Current Settings: Once in programming mode (above), use the ► button to scroll through all options (see table above).

The control will display the current setting for each option.

To Change Settings: Once in programming mode (above), press the ► button to select the desired option, then use the ▲ or ▼ buttons to scroll

through available settings (see table above). Select the desired setting and press the ENTR button.

To Exit Set-Up Menu: Press ESC button for three seconds to exit the Set-Up menu at any time. Any changes will be saved.

Example: To change the Motor Delay Off from 30 seconds to 15 seconds: Press and hold the ▲ + ► buttons for three seconds.

The screen will display

To Exit Setup, ESC for 3 seconds. Now press the ► button three times to get to the Motor Delay

Off option. The screen will display

Motor Delay Off and the current setting. Now press the ▼ button to select the 15 second

setting. Then press ENTR. The display will read

Entered. Press and hold the ESC button to exit the set-up menu.

To Restore Control Default Settings: Enter the programming mode (Press and hold the ▲ + ► buttons for three seconds). Using the ► button, scroll

to the

Factory Default option. Press the ▲ button to select Yes. Then press ENTR. The display will read Entered. Press and

hold the ESC button to exit the set-up menu.

Shaded box = default settings

Valve

Delay On

T.F.I.

Motor Delay

Off

Early Spark

Termination

Flame

Stabilize

Ignition

Type

Jumpered

Vent

Input

Allowed

Recycles

Baseline

Reset

Factory

Defaults

120

900

300

120

-10

Unlimited

-5

Smart

Intermittent

Yes

Used

Yes

Off

Interrupted

Not Used

None
