Fuses & power settings, On 8.0 – Carbolite RWF Series User Manual
Page 15
CWF, BWF, RWF
MF02 – 3.19
15
8.0 F
USES
&
P
OWER
S
ETTINGS
F1-F3: Refer to the circuit diagrams.
F1
Internal
supply
fuses
Fitted if supply cable fitted.
Fitted on board to some types of EMC filter.
on-board and up to 16 Amps:
32mm x 6mm type F
other: GEC Safeclip
F2
Auxiliary
circuit
fuses
Fitted on board to some types of EMC filter.
May be omitted up to 25Amp/phase supply
rating.
2 Amps glass type F
On board: 20mm x 5mm
Other: 32mm x 6mm
F3
Heat Light
fuses
May be omitted up to 25 Amp/phase supply
rating.
2 Amps glass type F
32mm x 6mm
Customer
fuses
Required if no supply cable fitted.
Recommended if cable fitted.
See rating label for amperage;
see table below for fuse rating.
Standard Models
Model
Phases
Volts
Supply Fuse
Rating
110
220
380
115
230
400
120
240
415
254
440
CWF -/5
1-phase
220-240
10A
100
100
100
89
CWF -/5
1-phase
110-120
20A
100
100
100
89
CWF -/13 1-phase
220-240
12.5A
100
100
100
89
CWF -/13 1-phase
110 / 120
25A / 30-32A
100
100
100
89
CWF -/23 1-phase
220-240
30-32A
100
100
100
89
CWF -/23 3-phase+N
380/220 - 415/240
12.5A/ph
100
100
94
83
CWF -/23 3-ph delta
220-240
20A
100
100
94
83
RWF -/5
1-phase
220-240
12.5A
100
100
100
89
RWF -/5
1-phase
110-120
25A
100
100
100
89
RWF -/13 1-phase
220-240
25A
100
100
100
89
RWF -/13 1-phase
110-120
50A
100
100
100
89
RWF -/13 2-phase+N
380/220 - 415/240
12.5A/ph
100
100
100
89
RWF -/23 1-phase
220-240
40A
100
100
100
89
RWF -/23 3-phase+N
380/220 - 415/240
12.5A/ph
100
100
100
89
RWF -/23 3-ph delta
220-240
25A/ph
100
100
100
89
USA models with 208V elements *; also 100V & 200V models
Model
Phases
Volts
Supply Fuse
Rating
100
200
208
220
230
240
CWF -/5
1-phase
208-240
12.5A
100
92
83
75
69
CWF -/13
1-phase
208-240
16A
100
98
87
80
74
CWF -/23
1-phase
208
40A
100
100
CWF -/23
3-ph delta
208
25A/ph
100
100
RWF -/5
1-phase
208-240
16A
100
100
89
82
75
RWF -/13
1-phase
208-240
25A
100
100
89
82
75
RWF -/23
1-phase
208
50A
100
100
RWF -/23
3-ph delta
208
25A/ph
100
100
* Up to 13 litre: for USA the 208V models are supplied, and power limit set accordingly. Amps ratings
are as for 208V, regardless of actual voltage.
BWF range - same as CWF
