HZS, TVS


MF24 – 3.44

13

7.4 Control by Broadcast comms (control method B)

When this is ordered there are three independent thermocouples (instead of the four shown)
connected to the three controllers; the controllers are linked together (not shown), and remain

“master” and “slave”.

The communication between the controllers of the Eurotherm 3000 series is known as Broadcast
comms. The wiring connections between the controllers are as follows:

7.5 Three-phase without neutral (delta, e.g. 208-240V)

7.6 Three phase without neutral (star – e.g. 380-415V)

The circuit is similar to 7.4, but the “neutral” ends of the
elements are not connected to a neutral terminal block.

The control circuit contains an isolating transformer to reduce
the control voltage to 240V or similar.

7.7 Higher Voltages (e.g. 254V)

For 254V or above, an isolating transformer is included
in the control circuit.

7.8 Model Configurations

These models normally have end zones of pair of elements each; the centre zone comprises the
remaining elements wired in parallel. By special order the zones can be of other lengths.

There are many possible electrical configurations for these models covering 1- 2- or 3-phase,
including 3-phase delta. Further information on the circuit diagram for a specific configuration can
be obtained from Carbolite (please state the furnace serial number).

HD

HE

HF

HD

HE

HF

HD

HE

HF

master

slave

slave

e

l

e

m

e

n

t

(s)

e

l

e

m

e

n

t

(s)

Control circuit as for single

phase

SSR

heat

on

F3

F1

F2

F3

L2

L3

L1

PE

SSR

SSR

F3

heat

on

F3

e

l

e

m

e

n

t

(s)

heat

on

F3

F3

contactor

Filter (if fitted)

F2

F2

transformer

Instrument Switch
