1.2 Specifications
Constructions
TTGEK Tank Sodalime glass, Kydex
TTGEK Lid Sodalime glass, Kydex
Electrodes Platinum wire .012” diameter
Power cords FR Polypropylene/Silicone, rated 7500V, 200mA, 65° C
TTGEK Cassette Acrylic
Cooling Coil brass, copper, PVC
Heater/Stirrer Buffer Cycler Stainless steel
Combs Teflon/ Acrylic
Spacers Proprietary
Glass Plates Sodalime or Borosilicate
Gradient Maker Acrylic, teflon, stainless steel
TTGEK-2401
Gel Size 17.7cm x 22cm
Distance between electrodes 20cm
Voltage limit 250
1.3 Safety
Power to the TTGEK Systems is to be supplied by an external DC voltage power supply that must be ground
isolated so that the DC voltage output floats with respect to ground. For any power supply used, the maximum
specified operating parameters for the units are:
Maximum Limits
250 VDC voltage
60 watts power
1600 mA current
70°C ambient temperature
Current to the unit, provided from the external power supply, must enter the unit through the lid assembly, providing
a safety interlock to the user. Current to the unit is broken when the lid is opened. Do not attempt to use the unit
without the safety lid. Always turn the power supply off before removing the lid, or when working with the
unit in any way. Follow safety precautions specified by the power supply manufacturer.
