MODE SETTINGS

１　⇔　２　⇔　３　⇔　４　⇔　Ｍ　⇔　ＯＦＦ　⇔　ＷＡＲＮ　⇔　Ｓ　

NOTE - When Scramble function is on, the "S" will blink.

EXPLANATION OF EVERY MODE

Mode - 1, 2, 3, 4

boost settings

Mode - Off

Mode - warning & limiter

red and an alarm should sound when warning is activated

( boost reduction level when warning mode is activated )

The warning & limiter is used to warn and prevent the user from over boosting or boost spikes.

Mode - Scramble boost

boost function.

is activated

Mode - Boost and peak hold

This mode displays current vehicle boost or vacuum.

This shows the highest level of boost achieved by the vehicle.

Modes in order when turning knob clockwise

NOTE - When the warning goes off, the "WARN" blinks and the screen turns red.

The DSBC allows the user to program in 4 independent

This mode turns off boost controller. The boost settings will return
to factory set specifications. The boost gauge and peak hold
can still be used in off mode.

This displays the user set warning level. The screen should turn

This mode displays the user set limiter setting

This displays the percentage of boost set for scramble

This displays the time duration (in seconds) scramble boost
