Page 10

Scramble boost allows the user to set an increase in boost pressure for a desired time.

MODE BUTTON

VOLUME BUTTON

IMPORTANT

of what the current channel is set on.

IN EXAMPLE

the total boost when scramble boost is activated will be at 60.

scramble boost. The letter " C " should appear.

IMPORTANT - To turn scramble boost off both " P " and " C " have to be set at 0.

When in channel 1, 2, 3, 4, M, or Off, pressing the volume knob will change to boost display
mode, peak hold mode, and boost setting mode.

*Peak hold records the highest boost pressure achieved by the vehicle.

SCRAMBLE MODE

- the scramble boost setting is an additional amount of boost added on top

- if channel 2 is set at 50, and the scramble boost is set at 10 then

This will continued every gear until the scramble boost is turned off.

To set the scramble boost mode turn mode button until " S " flashes.
1- Turn volume button to set to desired scramble boost. The letter " P " should appear.

2- Press volume button to enter time setting. Turn volume button to set the duration of

( Scramble time is set in duration of seconds )

BOOST GAUGE AND PEAK HOLD DISPLAY

*Peak hold remains in memory until the user resets the unit.

* To reset peak hold reading, switch modes to peak hold mode and press the Mode button.
