PARTS LIST

CONTROL UNIT

SPEC S SOLENOID *

SPEC R SOLENOID **

SPEC S HARNESS *

1 Pc.

SPEC R HARNESS **

PLASTIC HOSE

RUBBER HOSE

CLAMPS

1 Pc.

6 Pc.

PLASTIC HOSE JOIN

METAL T

PLASTIC T

PLASTIC REDUCER

1 Pc.

WIRE TAPS

PLASTIC TIES

NUT AND BOLT SET

DOUBLE SIDED TAPE

2 Pc.

6 Pc.

2 SET

1 Pc.

INSTALLATION MANUAL

* The Spec S boost controller and will come with the Spec S harness and Spec S solenoid.
** The Spec R boost controller and will come with the Spec R harness and Spec R solenoid.
* The harness for the Spec S boost control will not plug into the Spec R solenoid.
** The harness for the Spec R boost control will not plug into the Spec S solenoid.
