23
SINGLE UNIT (WITH FRONT MOUNTED CONTROLS)
3 ½
(89mm)
12 (306mm)
33 (838mm)
14 3/4 (375mm)
Push-Pull
Knob
Push-Pull Knob
Flue
7 (179mm)
10 5/8 (269mm)
Hinged Control
Access Panel
21 ½ (546mm)
2
(51mm)
38 (965mm)
36 (914mm)
Arched Opening
FC-516 24 (610mm)
FC-616/816 32 (813mm)
Lintel Plate & Main Burner Access
FC-516 44 3/4 (1137mm)
FC-616/816 56 3/4 (1441mm)
9 7/8 (251mm)
6 7/8 (175mm)
1 1/4 (32mm)
1 1/4 (32mm)
Side
Access
Cover 30 3/4 (782mm)
9 3/8 (237mm)
49 ½ (1257mm)
Deck Height
17
(430mm)
20 3/4
(527mm)
115VAC, 15A
NEMA 5-15P
Line Cord
115VAC, 15A
NEMA 5-15P
Line Cord
1 3/4 (44mm)
3/4 NPT
Gas Inlet
3/4 NPT
Gas Inlet
31 (787mm)
1 (25mm)
12 (305mm)
Booster Burner
Access Cover
11 ½ (293mm)
52 (1320mm)
Rear View
Left Side View
Front View
14
FC-516 26 (660mm)
FC-616 32 (813mm)
FC-816 35 (889mm)
FC-516/DS-805/D125 65 1/4 (1657mm)
FC-616 78 (1981mm)
FC-816 84 (2134mm)
FC-616/816
9 (229mm)
FC-516
3 3/4 (94mm)
FC-616/816
9 (229mm)
FC-516
3 3/4 (94mm) FC-516 15 ½ (395mm)
FC-616 16 3/4 (425mm)
FC-816 19 3/4 (502mm)
