12 AIR SUPPLY & VENTILATION (MODEL PB-24 EYE-BROW HOOD)
NOTE: Consult NFPA standard number 96 and local codes concerning ventilation
requirements and fire extinguishing system requirements.
Stainless Steel Finish Back
No. 4 Finish
(1) Component Hardware
Firefighter Series
Baffle type Grease Filters
(1) 16”H x 20”W Filters
Model #F60-1620
UL Classified
1 ½”x 1 ½”S/S
Mounting Angle
No. 7 Mirror Finish
4 (102mm)
24 (608mm)
2 (51mm)
92 3/4 (2357mm)
Top of Ventilator
88 3/4 (2255mm)
A.F.F.
Removable Grease Cup
12 (304mm)
