• Mode Sheet
MODE DESCRIPTION PARAMETERS
EXPLANATION
1
Units
Range = 1 - 3
1 - inches
2 - feet
3 - meters
Default = 2
2
Sensitivity
Units = %
Range = 0000-9999
3
Blanking
Units = Mode 1
Range = 2.0 to 50 ft.
Default = 2.00
4
Pulses
Units = Pulses
Range = 1 - 20
Default = 20
5
Sample Rate
Units = Seconds
Range = 0.120-1
Default = 0.120
6
Average
Units = Samples
Range = 1 - 200
Default = 10
7
Out-Of-Range
Units = Samples
Samples
Range = 1 - 200
Default = 5
8
Out-of-Range
Units = Mode 1
Span
Range = 0 - 9999
Default = 2.00
Select the units to be displayed and
used in setup. NOTE: * Set Mode 1
first before any other modes.
FOR VIEWING ONLY. The first
two digits display highest operating
sensitivity and the last two digits
display current sensitivity level.
Sets a dead zone in front of the
transducer where echoes are
ignored. The minimum dead zone is
required for the transducer to
change from a transmitter to a
receiver.
Sets the number of ultrasonic pulses
transmitted in each burst. 20 being
the strongest transmit setting.
Sets how fast the DCU-11 samples.
(1-8 sec. in autosense mode)
Sets the averaging size for the
FIFObuffer.
Sets the number of out-of-range
samples required before updating
the average (MODE 6).
Sets a window of acceptance for the
average (MODE 6). If a reading is out
of this window then it must be
followed by (MODE 7) more readings
before the average can be changed.
