Mode Sheet
MODE DESCRIPTION PARAMETERS EXPLANATION
1 Units Range = 0 - 2
0 - feet
1- inches
2 - mm
Default = 0
2 4mASet Point Units = Mode 1
Range = 0 - 9999
Default = 1.00
3 20mA Set Point Units = Mode 1
Range = 0 - 9999
Default = 25.00
4 Response Time Range = 1-3
Default = 1
1 = 3.3 ft/min (1m/min)
2 = 15ft/min (4.5m/min)
3 = >15 ft/min (4.5/min)
5 Fail-Safe Range = 0 - 2
Default = 0
0 = Hold last reading
1 = 22ma
2 = 3.75ma
6 Fail-Safe Units = seconds
Delay Range=5-9999
Default = 15
7 4mA Trim Range = 0 - 9999
Default = 5000
8 20mA Trim Range = 0 - 9999
Default = 5000
9 Calibration Range = 0000 - 1999
Default = 1000
Sets the units to be displayed and
used in setup. NOTE: Set Mode 1
before any other modes.
Sets the end point for the 4 mA
analog limit.
Sets the end point for the 20 mA
analog limit.
Sets the reaction rate of the sensor.
Sets the output status in the event
of a loss of echo condition.
Sets the delay in seconds before
the output will show a loss of echo
condition.
Fine tunes the 4 mA analog
output.
Fine tunes the 20 mA analog
output.
Sets the calibration factor.
Assume a decimal after first digit.
