Anchor CENTURY MATE 30 & 40" WIDE EXPANDABLE - Manual (Page 3)

30’ TENT LINE
45’ TENT LINE
SIDE POLE
(TYP)
CENTER
POLE
(TYP)
STAKE LINE
1’ LESS THAN
SIDE POLE
HEIGHT
END SECTION
USE DIAGONAL MEASUREMENT
TO SQUARE LAYOUT
END SECTION
MIDDLE
SECTION
LACE
LACE
3’-0”
15’-0” 15’-0” 15’-0”
**54’-1”
15’-0”
7’-6”
(TYP)
15’-0”
30’ X 45’ used as an example.
3
40’ TENT LINE
60’ TENT LINE
SIDE POLE
(TYP)
CENTER
POLE
(TYP)
STAKE LINE
1’ LESS THAN
SIDE POLE
HEIGHT
END SECTION
USE DIAGONAL MEASUREMENT
TO SQUARE LAYOUT
END SECTION
MIDDLE
SECTION
LACE
LACE
3’-0”
20’-0” 20’-0” 20’-0”
**72’-1¼”
20’-0”
10’-0” (TYP)
20’-0”
30’ EXPANDABLE
40’ X 60’ used as an example.
40’ EXPANDABLE
