7
Step 10
Snap kedared buckle to gable ends and adjust to create desired look at gable end slope.
Note: If liner appears loose after all kedared buckles are adjusted, pull-up ropes may require readjustment.
Gathered Liner Shown
Step 9
Before assembling rafters to frame,
kedared buckles must be inserted into the
bottom channel of the rafters. Examine the
gabled end liner that fi ts to the particular
rafter. Count the number of female side-re-
lease buckles on the slopes of that gable end
and insert the correct number of matching
kedared buckles into each bottom channel of
the corresponding rafter.
Kedared buckle
Kedar
Male side release
buckle
Kedared buckles inserted
into bottom channel of rafter
at gable end awaiting gable
end liner for connection.
Ridge
Gable end
eave beam
.. Snap buckles together and
tighten strap until liner has
the proper shape.
Do not over-tighten straps. S
Figure 9a
Figure 9b Figure 9c
