Allen & Heath 7 XONE:S2 User Guide
SPECIFICATIONS
Operating Levels
Input
RIAA input sensitivity
7-100mV 47K/330pF
Line Inputs
-10dB to +15dB RCA
Mic Sensitivity
-57 to –27dBu Balanced XLR
USB Audio In
0dBu RCA
Alarm Input
0dBu Phoenix connector
Mix Insert Return
-2dBu RCA
Filter External In
0dBu RCA
Output
Main Outputs
+4dBu XLR
Monitor -2dBu
RCA
Record -8dBu
RCA
Zone
+4dBu Balanced 1/4” TRS Jack
Mono
+4dBu Impedance Balanced XLR Sub Filter
Range 30Hz—250Hz
USB Audio Out
0dBu RCA
Mix Insert Send
-2dBu RCA
Filter External Out
0dBu RCA
Channel Insert Send
0dBu 1/4” TRS Jack
Frequency response Line in to Mix out
10Hz to 20kHz +/- 0dB (-1.5dB @ 50kHz)
Distortion at 1kHz Line in at +0Vu out
Typically < -0.05% Channel In to Mix out
Main Mix noise 22Hz—22kHz unweighted
< -73 dBu (-77dB S/N)
Residual Mix noise 22Hz—22kHz unweighted
< - 90.00 dBu
Equalisation
+6dB to minus infinity (total kill)
Fader Shutoff
> -86 dBr
Channel Insert Return
0dBu 1/4” TRS Jack
Dimensions and Weights
The console is fitted with rubber feet for desktop operation.
Width
Height
Depth
Weight
Mixer
482 mm (19“) 177 mm (7“) 123 mm (4.8”) 4.75 kg (10.5 lbs)
Packed
600 mm (23.6”) 300 mm (11.8”) 250 mm (9.8”) 7.5 kg (16.5 lbs)
