Allen & Heath 15 XONE:42 User Guide
6
7
FILTER SECTION
6 Frequency Sweep Control
This control sets the –3dB cut-off frequency of the filter.
It ranges from very low frequency (20Hz) to very high
frequency (20kHz).
NOTE: Both BPF and HPF filters are band limited to
prevent them going above 10kHz.
7 VCF to Crossfader
Press this switch to assign the filter to the crossfader. The
crossfader can then be used instead of the FREQ VCF
sweep control to create filter effects whilst crossfading.
The yellow LED next to the switch illuminates to indicate
that this control is active.
While using the crossfader to sweep the VCF frequencies,
the sweep control ranges from the left-hand (X) side of
the crossfader to the mid-point.
Disabling the crossfader will also disable this function.
