ORDERING A SPARES KIT
It is recommended that the spares kit order code 002-177 is held and maintained by the service agent to enable in-field
service repairs to the GL4000 independent of the ALLEN & HEATH factory. If you are an existing ALLEN & HEATH
service agent who already stocks the spares kit for the ALLEN & HEATH GL4, you may already stock some of the common
parts. A TOP-UP kit 002-178 is available which provides just the parts unique to the GL4000 range. Commonly available
items such as resistors, capacitors, tools and soldering equipment are not included. The contents of the kit is listed below
and is supplied in a cabinet of drawers. Individual spare parts may be ordered. Please quote the description and order
code for the part required.
A
-
GL4000 STANDARD SPARES KIT
B - GL4 TO GL4000 TOP-UP KIT
A
B
DESCRIPTION
ORDER CODE QTY
QTY
Fixings:
Screw 4AB x 5/16" Pan Pozi Black
AB0057
10
-
Screw 4AB x 5/16" CSK Pozi Black
AB0059
10
-
Screw 6B x 5/16" Pan Pozi Black
AB2084
10
-
Screw 8B x 5/16" CSK Pozi Black
AB2085
10
-
Screw 6B x 1/4" CSK Pozi zinc
AB2083
10
-
Screw 6B x 3/8" CSK Pozi zinc
AB2082
10
-
Screw M6 x 20mm CSK Allen Black
AB0310
5
-
Screw M3 x 5mm CSK Pozi Black
AB0070
10
-
Screw M3 x 8mm Pan Pozi Black
AB0073
10
-
Screw M3 x 8mm CSK Pozi Black
AB0074
5
-
Nylock Nut M3
AB0102
5
-
Fixing for D type connector
AB2189
10
-
Joint Block
AB0253
2
-
Plastic pillar snap-in
AB2233
4
4
Knobs and caps:
Knob Yellow & Grey 11mm D
AJ2079
10
-
Knob Dark Grey & Grey 11mm D
AJ2078
10
-
Knob Green & Grey 11mm D
AJ2077
10
-
Knob Blue & Grey 11mm D
AJ2075
10
-
Knob Brown & Grey 11mm D
AJ2080
10
-
Knob Red & Grey 11mm D
AJ2074
10
-
Knob Pale blue & Grey 11mm D
AJ2076
10
10
Fader Knob 11mm White+Black line Jungpoon* AJ2231
10
10
Fader Knob 11mm Red+White line Jungpoon*
AJ2230
5
5
Fader Knob 11mm Yellow+Black line Jungpoon* AJ2232
5
5
Fader Knob 11mm Blue+White line Jungpoon* AJ2663
5
5
Fader Knob 11mm White+Black line Alps*
AJ8078
10
-
Fader Knob 11mm Red+Black line Alps*
AJ8079
5
-
Fader Knob 11mm Yellow+Black line Alps*
AJ8080
5
-
Fader Knob 11mm Blue+Black line Alps*
AJ8081
5
-
Button 5.5mm Square Grey
AJ0363
10
-
Button 5.5mm Square Red
AJ0364
10
-
Button 5.5mm Square White
AJ0373
10
-
Button 10x5mm Rectangular Grey
AJ0093
10
-
Button 10x5mm Rectangular White
AJ0094
10
-
Button 10x5mm Rectangular Black
AJ0096
5
-
Button large illuminated white
AJ8107
10
10
* TO FIND OUT IF JUNGPOON OR ALPS K FADERS/FADER KNOBS CHECK CONSOLE SERIAL NUMBER WITH FACTORY
