ORDERING AN ASSEMBLY
The following assemblies are supplied fully tested. Please note that several of these need to be assigned according to
their position in the console. This is done by soldering wire links or assignment pads. It is best to check the assignment
settings of the assembly you are replacing before removing it from the console. Please quote the description and order
code for the part required.
Printed circuit (PCB) assemblies:
Mono Input Connector IN-8M CONN PCB assembly*
002-161
Mono Input PCB assembly
002-160
Stereo Input Connector IN-4SM CONN PCB assembly*
002-196
Stereo Input PCB assembly
002-195
Group 1-4 PCB assembly*+
002-162
Group 5-8 PCB assembly*+
002-163
Left / Right PCB assembly*+
002-197
Master PCB assembly
002-165
Master connector PCB assembly
002-166
Mono PCB assembly
002-164
Slave PCB assembly
002-167
MPU & 3 digit display PCB assembly
002-198
RPS11 PCB assembly
002-047
GL4000 Meterpod PCB assembly LEFT
002-039
GL4000 Meterpod PCB assembly RIGHT
002-040
GL4000M Meterpod PCB assembly LEFT
002-464
GL4000M Meterpod PCB assembly RIGHT
002-465
* Requires assignment
+ Quote Group Number, Left or Right
IDC connector harnesses:
GL4000-824/32/40 & 48
40 way Main harness
AL2636
GL4000-824 & 832
16 way left hand harness
AL2763
GL4000-840 & 848
16 way left hand harness
AL2764
GL4000-816 & 824
16 way right hand harness
AL2760
GL4000-832 & 840
16 way right hand harness
AL2761
GL4000-848
16 way right hand harness
AL2762
GL4000 (all formats)
16 way Master harness
AL2759
GL4000 (all formats)
16 way Meter harness
AL2733
GL4000 (all formats)
26 way MPU harness
AL2732
THE CHASSIS TRIM
GL4000 (all formats)
Left & Right Chassis side trims
AA2089L/R
GL4000M (all formats)
Left & Right Chassis side trims
AA3584-L/R
Write-on strip 10'
AK0327
GL4000-824 & 832
Ident strip CHAN 1-16
AK2637
GL4000-824 & 832
Ident strip CHAN 1-16 Rear
AK3112
GL4000-840 & 848
Ident strip CHAN 1-24
AK2638
GL4000-840 & 848
Ident strip CHAN 1-24 Rear
AK3113
GL4000-824 & 832
Ident strip GRP 1- CHAN 32
AK2639
GL4000-824 & 832
Ident strip GRP 1- CHAN 32 Rear
AK3114
GL4000-840 & 848
Ident strip GRP 1- CHAN 40
AK2703
GL4000-840 & 848
Ident strip GRP 1- CHAN 40 Rear
AK3115
GL4000-848
Ident strip CHAN 41-48
AK2704
GL4000-848
Ident strip CHAN 41-48 Rear
AK3116
GL4000 Meterpod
Left & Right Meterpod side trims
AA2090L/R
