Page 19

ALLEN & HEATH
Section A - 14
L4DSM2
ORDERING SPARE PARTS
ORDERING A CONSOLE
To order a new console please specify the model number required. Refer to the section: Standard Consoles for more detail
MODEL
DESCRIPTION
ORDER CODE
GL4000M-824A/B/C/D
24 Input channels with integral meterbridge + Power Supply GL4000M-824n
GL4000M-832A/B/C/D/E
28 Input channels with integral meterbridge + Power Supply GL4000M-832n
GL4000M-840A/B/C/D
36 Input channels with integral meterbridge + Power Supply GL4000M-840n
GL4000M-848A/B/C/D/E/F 44 Input channels with integral meterbridge + Power Supply GL4000M-848n
ORDERING AN OPTION
To order an option please specify the model number required:
GL4000-M24
Meterpod to fit 24 channel console
GL4000-M24
GL4000-M32
Meterpod to fit 32 channel console
GL4000-M32
GL4000-M40
Meterpod to fit 40 channel console
GL4000-M40
GL4000-M48
Meterpod to fit 48 channel console
GL4000-M48
GL4000-8M
8 Mono Input channel expander
GL4000-8M
GL4000-4SM
4 Mono + 4 Stereo Input channel expander
GL4000-4SM
GL4000-SL1
GL4000 SYS-LINK kit
GL4000-SL1
RPSD2
Dual supply Combiner / Monitor
RPSD-2
MANUALS AND SUPPORT DOCUMENTATION
DESCRIPTION
ORDER CODE
GL4000 Brochure
AP2641
GL4000 User Guide
AP2642
GL4000 Service Manual
AP2640
GL4000 Meterpod Fitting Instructions
AP2126
GL4000 SYS-LINK Fitting Instructions
AP2786
GL4000 SYS-LINK Application Note
AP2787
GL4000-8M / 4SM Fitting Instructions
AP2794
RPS11 User / Installation Guide
AP2725
RPSD-2 & RPSD User / Installation Guide
AP2263
SOFTWARE EPROM
To order a replacement EPROM, please contact ALLEN & HEATH and notify us of your console serial number, its present
EPROM version and code number and reason for the replacement.
GL4000 software
SERVICE TOOLS
The tools required to service the GL4000 are standard to an electronics service workshop and are easily obtainable. The
following items are necessary for disassembly and service access:
4mm Hexagon (Allen) key (M6 side trim)
AT0033
1-point Crosshead screwdriver (M3, 4AB)
AT0004
2-point Crosshead screwdriver (M4, 6AB)
AT0004
11mm Nutdriver (potentiometer nuts, headphone socket nuts)
12mm Nutdriver (jack nuts)
Torx-headed screw drivers
