ALLEN & HEATH 1 7 S1SM1
ORDERING A SPARES KIT
It is recommended that the spares kit order code 002-014 is held and maintained by the service agent to enable in-field
service repairs to the GS1 independent of the ALLEN & HEATH factory. Commonly available items such as resistors,
capacitors, tools and soldering equipment are not included. The contents of the kit is listed here. Individual spare parts
may be ordered. Please quote the description and order code for the part required.
DESCRIPTION ORDER CODE QTY
Fixings:
Screw 4AB x 5/16" Pan Pozi Black AB0057 10
Screw 6AB x 3/8" Pan Pozi Black AB0062 5
Screw M3 x 8mm Pan Pozi Black AB0073 10
Screw 6B x 1/4" Pan Pozi Black AB2224 5
Nylock nut M3 AB0102 5
Washer M3 shakeproof AB0244 5
Pillar Support 6.4mm AB2171 5
Pillar snap-in 6.4mm AB2233 5
Spacer M3 x 6.4mm AB2218 5
Knobs and caps
Fader knob white+black line AJ2163 10
Fader knob red+white line AJ2164 5
Rotary knob grey+red top AJ2188 10
Rotary knob grey+blue top AJ2194 10
Rotary knob grey+green top AJ2195 5
Rotary knob grey+dark grey top AJ2196 10
Rotary knob grey+yellow top AJ2197 10
Rotary knob grey+brown top AJ2198 10
Switch Button AJ8071 10
Potentiometers, switches and connectors
Fader 10kA 100mm ALPS - MONO AI8055 5
Fader 10kAx2 100mm ALPS - STEREO & LR AI8056 5
Rotary 200kC stereo - MID SWEEP AI2042 3
Rotary 5kRD - MIC GAIN AI8059 5
Rotary 20kB centre click - HF,MF,LF AI8060 10
Rotary 20kK - AUX 2/4, 3/5, TAPE RTN LEV, AUX MASTERS AI8061 10
Rotary 5kB centre click - PAN AI8062 5
Rotary 20kK stereo - AUX 1, STEREO RTN LEV & MONITOR LEV AI8063 10
Rotary 20kBx2 - STEREO HF & LF AI8064 5
Switch 2PCO latching AL8057 5
Switch 2PCO momentary AL8058 5
Jack socket - LINE, INSERT, STR RETURN AL8072 5
Jack socket - AUX OUTS, HPHONES AL8073 5
XLR 3 Pin Female - MIC AL8074 5
Dual Phono socket - TAPE IN/OUT, LR OUT AL0577 3
DIN 5 Pin 180º - MIDI AL0095 1
DIN 5 Pin 240º - CONSOLE POWER AL2113 -
LEDs and Semiconductors
LED 3mm T1 Green AE0085 5
LED 3mm T1 Red AE0086 3
LED Bar 4x Green AE0303 2
LED Bar 1x Green + 3x Red AE0347 1
Transistor BC214C PNP AE0031 5
Transistor BC546C NPN AE2253 5
Transistor 2SB737 PNP AE8069 5
Transistor J111 FET AE0083 5
IC NE5532N Dual Op Amp AE0221 5
