ORDERING AN ML5000 SPARES KIT
It is recommended that the spares kit order code 002-533 is held and maintained by the service agent
to enable in-field service repairs to the ML5000 independent of the ALLEN & HEATH factory.
Commonly available items such as resistors, capacitors, tools and soldering equipment are not
included. The contents of the kit are listed below and are supplied in a cabinet of drawers. Individual
spare parts may be ordered. Please quote the description and order code for the part required.
Fixings:
DESCRIPTION ORDER CODE QTY
Screw 4AB x 5/16” CSK Pozi Black AB0059 20
Screw M3 x 8 CSK Pozi Black AB0074 10
Nylock Nut M3 AB0102 10
Nylock Nut M4 AB0105 10
Screw 4AB x 1/2" Pan Pozi Black AB0250 10
Screw M6 x 20 CSK Allen Black AB0310 5
Screw 6B x 3/8 CSK Pozi Zinc AB2082 20
Screw 8B x 3/8 CSK Pozi Black AB2085 5
Screw 6B x 5/16 Pan Pozi Black AB2809 20
Screw 4 x 5/16 Poly Pan Pozi Black AB2810 20
Screw M3 x 5 CSK Pozi Black AB2811 20
Screw M3 x 4 TT Hex Head Black AB3837 20
Screw M6 x 10 CSK Pozi Zinc AB4036 5
Screw 6B x 3/8 Flange Headed Pozi Black AB4037 10
Rivet Plastic Snap SR3535B AB4092 5
Pot Nut 9mm AB8050 50
Knobs and caps:
DESCRIPTION ORDER CODE QTY
Knob Red & Grey 11mm D AJ2074 10
Knob Blue & Grey 11mm D AJ2075 40
Knob Light Blue & Grey 11mm D AJ2076 40
Knob Green & Grey 11mm D AJ2077 15
Knob Dark Grey & Grey 11mm D AJ2078 15
Knob Yellow & Grey 11mm D AJ2079 10
Knob Brown & Grey 11mm D AJ2080 10
Button 10x5mm Rectangular Grey AJ2865 2
Button 10x5mm Rectangular Black AJ3228 1
Fader Knob 11mm Black + White Line AJ3503 15
Switch Cap Grey 6x6mm Offset AJ3863 20
Button Illuminated Red AJ3949 2
Switch Cap White Offset AJ3950 20
