4. Web Configuration
AirLive N.Plug User’s Manual
31
2.4GHz (G+N): 802.11g supported rate and 802.11n
supported rate.
2.4GHz (B+G+N): 802.11b, 802.11g and 802.11n supported
rate.
Local SSID
A SSID is referred to a network name because essentially it is a
name that identifies a wireless network(case-sensitive).
Remote SSID
In Repeater Mode, the remote SSID should be the same with the
repeated Router or AP.
Channel Width
This function will be available under 2.4GHz (N), 2.4GHz (G+N),
2.4GHz (B+G+N) mode. Select 20MHz the channel number will
be form 1~11 and auto; Select 20/40MHz channel width the
channel number will be form 5~11 and auto. Default is 20/40MHz.
Control Sideband
This function will be available under 2.4GHz (N), 2.4GHz (G+N),
2.4GHz (B+G+N) mode. Select upper or lower form the pull-down
list, default is upper.
Channel Number
The channel number will be set the same as remote Ap
automatically.
Broadcast SSID
Enabled: This Wireless Router will show its network name(SSID)
to stations.
Disabled: This Wireless Router will hide the network name to
stations. If stations want to connect to this Wireless Router, this
Router’s network name(SSID) should be known in advance to
make a connection.
WMM
The Wi-Fi Multiple Media function is available under 2.4GHz (B),
2.4GHz (G) and 2.4GHz (B+G) band, and it is disabled under
2.4GHz (N), 2.4GHz (G+N) and 2.4GHz (B+G+N) band.
Data Rate
There are several data rate that you can select from the pull-down
menu.
Associated Clients
Click button to show all connected clients.
