AirLive BU-3026-IVS - Manual (Page 40)

6. Configuration
AirLive BU-3026/BU-3026-IVS User’s Manual 36
- Password: Enter the password to login into the FTP server
- File Path Name: Enter the port number used for the FTP server.
- Test FTP: You can test the FTP server function first here.
Note: Due to the network environment, the camera may not upload number of
images that you set.
z SMTP Server: Select “Enable” to enable the SMTP server function.
- SMTP Mail Server: Enter the mail server address. For example, mymail.com .
- Port: Assign the SMTP port in the text box. The default SMTP port is 25.
- Sender Email Address: Enter the email address of the user who will send the email.
For example, [email protected] .
- Receiver #1/#2 Email Address: Enter the first/second email address of the user
who will receive the email.
- Subject: Enter the subject of the message for the event.
- Authentication: Select the option according to the mail server configuration.
- User Name: Enter the user name to login the mail server.
- Password: Enter the password to login the mail server.
- Test SMTP: When done, click the button to test the SMTP server function.
- Requires SSL Encryption: If the mail server requires an encrypted connection, you
should select the SSL option.
- STARTTLS: Select it if the server needs the STARTTLS encryption.
Note: Due to the network environment, the camera may not upload number of
images that you set.
z Samba Event Server: Select “Enable” to enable the Network Storage server for
the camera.
- Samba Server Address: Enter the IP address of the Network Storage server.
- Path: Assign the path for uploading the files on the Network Storage server.
- User Name: Enter the user name to login into the Network Storage server.
- Password: Enter the password to login into the Network Storage server.
- Test SMB: When done, click the button to test the network storage server function.
Note: The recorded video files in Network Storage are enclosed by MP4/AVI format
without audio.
