6. Configuration
AirLive BU-3026/BU-3026-IVS User’s Manual 28
z Main Stream & Second Stream: It enables the encoder to deliver two totally
independent streams of video, separately configured for different frame rates and
video resolutions.
- Video Resolution: Select the resolution that you want to see the image on screen
from the pull-down menu. It supports several resolution as below:
1. 2048 x 1536 (3M)
2. 1920 x 1080 (1080P)
3. 1280 x 1024 (SXGA)
4. 1280 x 960 (960P)
5. 1280 x 720 (720P)
6. 720 x 480 (D1)
7. 640 x 480 (VGA)
8. 320 x 240 (QVGA)
9. 176 x 144 (QCIF)
You also need to select a proper Frame Rate setting.
In Intelligent Analysis Mode:
1. 2048 x 1536 (3M)
2. 1920 x 1080 (1080P)
3. 1280 x 1024 (SXGA)
4. 1280 x 960 (960P)
5. 1280 x 720 (720P)
Please be noted that higher resolution and frame rate gets better video quality but
larger network bandwidth.
- Main Stream / Second Stream: Select the streaming format as H.264
(High/Main/Baseline Profile) / MPEG4 / MJPEG.
- Rate Control: Set the proper image quality by selecting Video Quality (VBR) or
Bitrate (CBR) and then select the desired settings from the pull-down menu.
Select Very Low, Low, Normal, High or Very High for VBR.
Input a bitrate range from 384Kbps to 6Mbps for CBR.
- GOV: Set the GOV value by 1~100 seconds.
z Mobile View (Not supported by MPEG4): The camera supports 3GPP specification.
Select the Disable option to disable this feature. Otherwise, select 3GPP Without
Audio or 3GPP With Audio to transfer the video clips without or with audio.
