A.2 – MXL Strada/Pista wirings
Materiale / Material Q.tà / Q.ty Rif. / Ref.
Progettato da / Designed by Contr. da / Ckd. by Approvato da / Approved by Nome file / File name Data / Date
N. articolo / Item N.
Scala / Scale
Foglio / Sheet Rev. / Rev.
Titolo / Title
N. disegno / Drawing N.
N.rev. / Rev. N. Descrizione / Description Data / date Firma / Sign Contr. da / Ckd. by
Racing Data Power
AMP 12 pins
female
connector
6 - 0.5 mm
unifilar cables
500 mm RS 232
white
blue
6
5 RS 232 RX
RS 232 TX
500 mm
500 mm
white
blue
CAN
Power
red
black
4
3
2
1 VB ext (9 -15 VDC)
GND
CAN +
CAN -
6 5 4 3 2 1
12 11 10 9 8 7
AMP 12 pins
female connector pinout
Contact insertion view
Channels Cable Colour AMP 12 pin Connection Length
Non cabled channels table
MXL Strada standard cable
Cavo Standard MXL Strada
1 of 1
L.I.
04.554.09
