DOUBLE WIDE STAGE POCKET SPECIFICATIONS

ACE BACK

STAGE CO., IN

CLEAR C

DMX12

PUSH

(2) CAPTIVE SLOT CLOSURES

DR OP INT O BOX WHEN

CA BLE WA Y S LOT IS IN USE

OPTIONAL BACK BOX WEL

DED 14 GAUGE

(.071" THICK) STEEL 10" X 18" X 6" ZINC

PLATED (A CE #104BBX BACK BOX) OR

OPTIONAL BACK ACCESS COVER 14 GAUGE

(.071" THICK) STEEL ZINC PL

ATE D (ACE

#24BAC BACK ACCESS COVER - NOT SHOWN)

REMOVABLE HINGE PINS

PERMIT EASY LID

EXCHANGE FOR

CUSTOM LID

CONFIGURATIONS

.375" CABLE WA

Y S LOT

18.500"

16.000"

TRIM BEZEL

10.500"

6.000"

4.500"

59/64"

NOM.

TOP VIEW

FRONT VIEW

4.500"

6.000"

NOMINAL

OPENING

"CONNECTRIX"

A F LEXIBLE CONNECTOR

AND PANEL SYSTEM

Choose Pre-fabricated audio,

communications, data, electric,

video, and voice connectors and

panels or create custom panels

as needed using the "Connectrix"

System of panels and connectors.

10.000"

SECTION VIEW

OPEN

BACK

ACCESS

16.000"

18.000"

16.240"

1.250" TYPICAL TRIM BEZEL

.500"

16 GAUGE (.060" THICK)

WELDED STEEL

POCKET

BODY CONSTRUCTION

1.500" NOMINAL

8.000"

7.187"

3.656"

1.875"

NOM.

16.8" x 8.5" CUTOUT

IN STAGE

FLOOR WHEN MOUNTING IN

STAGE FLOOR

WITHOUT

ACE #104BBX BACK BOX

11 GAUGE (.120" THICK) STEEL TRIM BEZEL

AND LID ASSEMBL

Y W ITH POWDER COAT

FINISH INSIDE AND OUTSIDE

• ANTIQUE COPPER VEIN

• ANTIQUE SILVER VEIN

• TEXTURED BLACK

• BRUSHED BRASS*

• STAINLESS ST

EEL*

*Solid Brass or Stainless Steel Metal

Finish Available as Special Order

4 of 4

ACE BACKSTAGE CO., INC.

STAGE POCKET SYSTEMS

24846 Avenue Rockefeller | Suite 200 | Valencia, CA 91355

Tel: 661-295-5760 | Fax: 661-295-1122

Email: [email protected] | Web: www.acebackstage.com

DATA SHEET

Stage Pocket

Data Spec Sheet

Revision: 1B.124-224

Model Numbers:

#124-xxyy, #224-xxyy (xx= Lid Type and yy= Finish Type)

Model Name:

Double Wide Stage Pocket - Extra Large Capacity Standard general use Vertical Slant Panel Pocket

Model Description: Pocket with brushed metal or powder coat finish, choice of lid, with optional panel(s) and connectors
