• (16) #8 Self Tapping Sheet Metal/Wood Screws

• (2) Slot Closures

SPECIFICATIONS

ACE Double Wide Stage Pocket Size:

• Double Wide Stage Pocket Body Size:

16.000” W x 4.500” H x 7.156” D

• Double Wide Stage Pocket Lid & Mounting Flange Size:

18.500” W x 0.937” H x 10.500” D

ACE Double Wide Stage Pocket Connector Capacity:

• 24 “Connectrix”, Neutrik®, or Switchcraft® Connectors

ACE Double Stage Wide Pocket Install Cutout Dimensions:

• 16.500” W x 8.500” H

ACE Double Wide Stage Pocket Material:

• CRS Steel and/or Solid Half Hard Brass

ACE Double Wide Stage Pocket Panel Capacity:

• (4) #PNL-100 Series “CONNECTRIX” Panels OR

• (4) #PSW-100 Series Switchcraft® Panels OR

• (4) #PE Series Single Gang Electric Duplex Switch Box Panels OR

• (2) #FP3E Series Triple Gang Electric Duplex Switch Box Panels OR

• (2) #PNL-120 Series “Connectrix” Panels OR

• (4) Any combination of four Panels #PNL-100, #PE, #PSW-100

• (2) Any combination of two Panels #PNL-120, #FP3E

CONNECTOR CAPACITY

ACE Double Wide Stage Pocket Connector Capacity:

• 24 “Connectrix”, Neutrik®, or Switchcraft® Connectors

“CONNECTRIX” Connectors combine Neutrik® “D”

and Switchcraft® “E” Mounting Hole Patterns for

Greater Flexibility

The “CONNECTRIX” system connectors may be used in

any of the “CONNECTRIX” system panels utilizing our

“CONNECTRIX” cutout which incorporates the popular

mounting pattern of the Neutrik “D” and Switchcraft “E”

series mounting patterns. Connectors using the generous

rectangular “CONNECTRIX” cutout will add to a growing ar-

ray of adapter-mounted standard connectors. The adapter

mount is plastic and provides ground isolation between the

panel and connector.

When ordering, please specify connector model number,

model name, and type of connector as well as panel model

number (#PNL-100 Series, #PNL-120 Series, or #PNL-140

Series) the connectors will be loaded into. NOTE: Specific

High Density (HD) and Sub-D pattern connectors will re-

quire either 2 or 3 “CONNECTRIX” Horizontal Spaces or 2

or 3 “CONNECTRIX” Vertical Spaces, depending on connec-

tors selected. Connectors may be loaded into panels with

nutcerts and nut/bolts or black aluminum pop rivets.

ACE Double Wide Stage Pockets Connector Types:

• “Connectrix” Connectors (fits Neutrik®/Switchcraft®)

• Switchcraft® Connectors

• Custom Panel Connectors (custom panel cutout required)

PANEL CAPACITY

ACE Double Wide Stage Pockets Panel Capacity:

• (4) #PNL-100 Series “CONNECTRIX” Panels OR

• (4) #PSW-100 Series Switchcraft® Panels OR

• (4) #PE Series Single Gang Electric Duplex Switch Box Panels OR

• (2) #FP3E Series Triple Gang Electric Duplex Switch Box Panels OR

• (2) #PNL-120 Series “Connectrix” Panels OR

• (4) Any combination of four Panels #PNL-100, #PE, #PSW-100

• (2) Any combination of two Panels #PNL-120, #FP3E

“CONNECTRIX” SYSTEM PANEL DESCRIPTION

Many pre-cut stock #PNL-100 Series, #PNL-120 Series

“CONNECTRIX” System connector panels and #PSW-100

Series Switchcraft® connector panels are available for the

Double Wide Stage Pocket. Standard “CONNECTRIX” and

Switchcraft® Panels are created from high strength, tough,

aircraft aluminum alloy (6061-T6) that is 1/16” (.062”) or

1/8” (.125”) thick.

The standard panels mount with (4 or 6) self-tapping screws.

Each panel is CNC machined to precisely mate with the

designated connectors and in the pocket mounting holes.

Each Standard “CONNECTRIX” and Switchcraft® Panel is

finished with oven cured semi-gloss black powder coat.

Most panels provide header space for custom engraving

which is fast and easily accomplished on a separate dedi-

cated CNC engraving machine. The finished panels show

bright aluminum in the engraved characters and need not

be back filled. ACE standard panels are flat, strong, and

rigid like the typical thinner mild steel panels. Because

the panels are machined and not punched they stay flat

and undistorted unlike punched panels which distort in the

punching process.

The machined “CONNECTRIX” style cutouts combine popular

mounting patterns of the Neutrik “D” series and Switchcraft

“E” series connectors with a generous rectangular cutout

that mates with a growing array of adapter-mounted

standard connectors. The adapter mount is plastic and

provides ground isolation between the panel and connector.

Using the “CONNECTRIX” system panel it is possible to

mount any combination of modular jacks (RJ45, RJ11 etc.),

BNCs, dual RCAs, mic jacks, speaker jacks and numerous

other standard connectors without a single custom punch.

This system provides for more connectors and mounting

options in stock standard ACE panels. The benefit is faster

order turn around and lower cost. Less custom fabrication

for custom spec results with off-the-shelf stock prices.

ACE BACKSTAGE CO., INC.

STAGE POCKET SYSTEMS

24846 Avenue Rockefeller | Suite 200 | Valencia, CA 91355

Tel: 661-295-5760 | Fax: 661-295-1122

Email: [email protected] | Web: www.acebackstage.com

DATA SHEET

Stage Pocket

Data Spec Sheet

Revision: 1B.124-224

Model Numbers:

#124-xxyy, #224-xxyy (xx= Lid Type and yy= Finish Type)

Model Name:

Double Wide Stage Pocket - Extra Large Capacity Standard general use Vertical Slant Panel Pocket

Model Description: Pocket with brushed metal or powder coat finish, choice of lid, with optional panel(s) and connectors
