the CONNECT message.
Minimum ring duration to send SMS at no answer [s] – set the minimum ringing
timeout for sending the SMS at no answer.

Note

The INVITE message must contain the called and calling numbers in
order that the

function may work properly.

SMS at no answer

Delay for ALERTING [a] – set the delay before sending the ALERTING message.
Minute parameter – define whether the GSM gateway shall consider call duration
or count while limiting outgoing calls.
Day of deleting statistics in group (every month) – set a day on which statistic
data on disconnected calls shall be deleted.
Generate virtual ring tone – enable/disable generation of the virtual ringing tone
into the VoIP interface.
Call length counting – define whether call minutes or seconds shall be counted.
BTS lock – identify the BTS to which the GSM modules shall log in. Restart the
selected GSM modules to execute the changes.

Caution

The BTS lock service work with specific GSM modules only (Q55)!
If you set a wrong BTS lock, the selected GSM module(s) will not log
in to GSM.

After call relax delay – set the time between the end of the current call and start
of the next call via one and the same GSM/UMTS module. The recommended
value for heavy–traffic installations is 2 seconds!
Add random time – use this auxiliary parameter to add random time in seconds.
Thus, the resultant time is the sum of the two above mentioned parameters.

Disconnect call

Set the reasons for immediate discontinuation of an outgoing call to GSM/UMTS.

Send CLIP from VoIP to GSM/UMTS

Transfer CLIP to GSM/UMTS – enable/disable the function.
Separating char – define the CDN/CLIP separating character.
Modify (‘–’ remove one digit) – change the CLIP. The ‘–’ character is used for
deleting one character from the left.

Caution

The

service must be supported by the

Send CLIP from VoIP to GSM

GSM/UMTS provider's network. Otherwise, the call may be rejected by
GSM/UMTS!

GPRS activation

APN string

– define the Access Point Name (APN) for GPRS connectivity.
