PTO CHIPPERS iv
TAbLE oF CoNTENTS
dESCRIPTIoN PAGE dESCRIPTIoN PAGE
SAFETY ......................................................................... 1
1.1 SAFeTY AleRT SYMBOl ........................................ 1
1.2 eMISSION INFORMATION ....................................... 1
1.3 BeFORe OPeRATING .............................................. 1
1.4 OPeRATION SAFeTY .............................................. 2
1.5 Feed ROlleR SAFeTY .......................................... 2
1.6 MAINTeNANce/STORAGe SAFeTY ....................... 3
1.7 TOWING SAFeTY ..................................................... 3
1.8 PTO SAFeTY ............................................................ 3
1.9 SAFeTY decAl lOcATIONS ................................. 4
1.10 SAFeTY decAlS ................................................... 5
ASSEmbLY .................................................................... 6
2.1 ATTAch chuTe SuPPORT (hYdRAulIc Feed
MOdelS ONlY) ........................................................ 6
2.2 ATTAch chIPPeR chuTe ...................................... 6
2.3 ATTAch exTeNSION TRAY ..................................... 7
2.4 hYdROSTATIc cONTROl cABle .......................... 7
2.5 SAFeTY BAR ............................................................ 7
2.6 ATTAch dISchARGe TuBe .................................... 7
2.7 ATTAch dISchARGe TuBe .................................... 8
2.8 cONNecT PTO ShAFT............................................ 8
FEATuRES & CoNTRoLS ............................................ 9
oPERATIoN ................................................................ 10
4.1 STARTING The chIPPeR ...................................... 10
4.2 STOPPING The chIPPeR ...................................... 10
4.3 OPeRATING The chIPPeR .................................. 10
4.4 Feed ROlleR cONTROl BAR .............................11
4.5 lOck exTeNSION TRAY INTO TRAVel POSITION 11
SERvICE & mAINTENANCE ....................................... 12
5.1 chIPPeR BlAde MAINTeNANce ........................ 13
5.2 ReMOVING The BlAdeS ..................................... 13
5.3 ShARPeNING The BlAdeS ................................. 13
5.4 AdjuSTING The chIPPeR ANVIl ........................ 14
5.5 lOFA cONTROl PROGRAMMING ........................ 14
5.6 luBRIcATION ........................................................ 15
5.7 PTO dRIVelINe luBRIcATION ............................ 16
5.8 cleARING PluGGed ROTOR .............................. 16
5.9 AdjuSTING/RePlAcING dRIVe BelT .................. 17
5.10 RePlAcING BeARINGS ...................................... 17
5.11 chANGING hYdRAulIc OIl FIlTeR .................. 17
5.12 FIllING hYdRAulIc FluId................................ 17
TRoubLESHooTING ................................................. 18
SPECIFICATIoNS ........................................................ 19
7.1 chIPPeR SPecIFIcATIONS ................................... 19
7.2 BOlT TORQue ........................................................ 20
