PTO CHIPPERS 19
ENGLISH
Section
SPECIFICATIoNS
7.1 CHIPPER SPECIFICATIoNS
7
CH8540
dESCRIPTIoN ENGLISH mETRIC
OVeRAll SIZe 45" x 47" x 90" 114 x 119 x 229 cm
OVeRAll WeIGhT 885 lBS. 402 kg
MAx chIPPeR cAPAcITY 8" 20 cm
chIPPeR BlAdeS 4 4
chIPPING ANVIl 9.25" x 3.5"' x .63"23.5 x 8.9 x 1.6 cM
dISc SPeed 1500 RPM 1500 RPM
dISc SIZe 30" dia. x 1.25" 76 cm x 3.2 cm
dISc WeIGhT 247 lbs. 112 kg
dISchARGe TuBe SIZe 32" x 36" 81 cm x 91 cm
dISchARGe TuBe heIGhT 95" 2.41 m
dRIVe TYPe Belt Belt
dRIVe BelT SIZe 3RB64.5 (67.5”)
3RB64.5
(171.45 cm)
SPlINe SIZe
1.375" diameter
(6 SPlINe)
3.49 cm diameter
(6 SPlINe)
3 POINT hITch category 1 category 1
PTO 540 +/- 10 RPM 540 +/- 10 RPM
CH9540H
dESCRIPTIoN English metric
OVeRAll SIZe 45" x 47" x 90" 114 x 119 x 229 cm
OVeRAll WeIGhT 885 lBS. 402 kg
MAx chIPPeR cAPAcITY 9" 23 cm
chIPPeR BlAdeS 4 4
chIPPING ANVIl 9.25" x 3.5"' x .63" 23.5 x 8.9 x 1.6 cM
dISc SPeed 1500 RPM 1500 RPM
dISc SIZe 30" dia. x 1.25" 76 cm x 3.2 cm
dISc WeIGhT 247 lbs. 112 kg
dISchARGe TuBe SIZe 32" x 36" 81 cm x 91 cm
dISchARGe TuBe heIGhT 95" 2.41 m
dRIVe TYPe Belt Belt
dRIVe BelT SIZe 3RB64.5 (67.5”)
3RB64.5
(171.45 cm)
hYdRAulIc BelT SIZe Bx44 (45.8”) Bx44 (116.33 cm)
hYdRAulIc Feed RATe 0-150 ft/min 0-46 m/min
hYdRAulIc OIl TANk
cAPAcITY
3 gal. 11.3 l
SPlINe SIZe
1.375" diameter
(6 SPlINe)
3.49 cm diameter
(6 SPlINe)
3 POINT hITch category 1 category 1
PTO 540 +/- 10 RPM 540 +/- 10 RPM
CHF9540H (FINE CHIP)
dESCRIPTIoN ENGLISH mETRIC
OVeRAll SIZe 45" x 47" x 90" 114 x 119 x 229 cm
OVeRAll WeIGhT 885 lBS. 402 kg
MAx chIPPeR cAPAcITY 9" 23 cm
chIPPeR BlAdeS 16 16
chIPPING ANVIl 9.25" x 3.5"' x .63" 23.5 x 8.9 x 1.6 cM
dISc SPeed 1500 RPM 1500 RPM
dISc SIZe 30" dia. x 1.25" 76 cm x 3.2 cm
dISc WeIGhT 275 lbs. 125 kg
dISchARGe TuBe SIZe 32" x 36" 81 cm x 91 cm
dISchARGe TuBe heIGhT 95" 2.41 m
dRIVe TYPe Belt Belt
dRIVe BelT SIZe 3RB64.5 (67.5”)
3RB64.5
(171.45 cm)
hYdRAulIc BelT SIZe Bx44 (45.8”) Bx44 (116.33 cm)
hYdRAulIc Feed RATe 0-150 ft/min 0-46 m/min
hYdRAulIc OIl TANk
cAPAcITY
3 gal. 11.3 l
SPlINe SIZe
1.375" diameter
(6 SPlINe)
3.49 cm diameter
(6 SPlINe)
3 POINT hITch category 1 category 1
PTO 540 +/- 10 RPM 540 +/- 10 RPM
