3120893 5-3
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-1. LIFT CYLINDER COMPONENTS ASSEMBLY (PRIOR TO S/N 26916)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LIFT CYLINDER SUB-ASSEMBLY Ref.
1 to 22 Not Used Locknut 1
23 0641506 Bolt 5/16”-18NC x 3/4” 2
24 0100011 Loctite #242 A/R
25 4640717 Cartridge, Valve (Manual Descent) 1
26 3311402 Nut, Jam 1/4”-20NC 1
27 0080190 Adapter 1
28 4220044 Stop, Throttle 1
29 0902151 Bracket 1
30 Cable Assembly Options: 1
1060377 Prior to S/N 28133 - Use 1060643 as Replacement
1060643 S/N 28133 to Present
31 3450405 Pin, Cotter 1
32 3321402 Nut, Jam 1/4”-28NF 4
33 4711400 Flatwasher 1/4” Narrow 4
34 3760170 Ring (Prior to S/N 28133) 1
35 3841127 Rod, Manual Descent (Prior to S/N 28133 Only) 1
1683363 LIFT CYLINDER ASSEMBLY Ref. C
101 1683353 Barrel Weldment 1
101A 0962012 Bushing, Garmax 2
102 1683355 Rod Weldment 1
102A 0962012 Bushing, Garmax 2
103 1683061 Head 1
104 3480211 Piston 1
105 4565008 Spacer 1
106 0961897 Bushing, Tapered 1
107 Not Used
108 4640509 Cartridge, Valve 1
2900792 Seal, Kit - 4640509 Valve 1
109 3931720 Capscrew 7/16”-14NC x 1 1/4” 8
110 3760370 Ring, Washer 1
111 2220883 Plug, Fitting 3
112 Kit Wiper 1
113 Kit Seal, Rod 1
114 Kit O-Ring 1
115 Kit Ring, Back-Up 1
116 Kit Ring, Wear 1
117 Kit O-Ring 1
118 Kit Ring, Back-Up 1
119 Kit Ring, Lock 2
120 Kit Seal 2
121 0100011 Loctite #242 (Not Shown) A/R
122 0100038 Primer, Locking (Not Shown) A/R
123 Not Used
