SECTION 1 FRAME
.
FIGURE 1-5. DRIVE AXLE ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0280150 DRIVE AXLE ASSEMBLY Ref.
⎯
1 7019033 Housing 1
2 7019000 Drive Gear & Pinion 1
3 7019001 Bearing, Inner Pinion 1
4 Kit Shim, Drive Pinion Adjusting A/R
5 7019003 Baffle, Pinion Bearing 1
6 Kit Shim, Pinion Bearing Adjusting A/R
7 7019004 Bearing, Outer Pinion 1
8 7019005 Slinger, Outer Pinion Bearing 1
9 7019006 Seal, Pinion 1
10 7019007 Yoke Assembly 1
11 7019008 Washer, Pinion Nut 1
12 7019009 Nut, Pinion 1
13 Not Used
14 7019010 Cover, Carrier 1
15 7019011 Gasket 1
7019012 Sealant (Not Shown) A/R
16 7019013 Plug 1
17 7019014 Bolt, Carrier Cover 10
18 7019015 Cap, Differential Bearing 2
19 7019016 Bolt, Differential Bearing Cap 4
20 7019017 Bearing, Differential 2
21 Kit Shim, Differential Bearing A/R
22 Not Used
23 7019019 Bolt, Differential Case 10
24 to 29 Not Used
30 7019020 Bolt, Axle Shaft 8
31 7019021 Nut, Axle Shaft 8
32 7019022 Seal, Inboard Shaft 2
33 7019023 Ring, Wheel Bearing Retaining 2
34 7019024 Bearing, Axle Shaft Wheel 2
35 7019025 Seal, Outboard Shaft 2
36 7019026 Retainer, Axle Shaft 2
37 7019027 Shaft, Axle 2
38 7019034 Bolt, Wheel 10
39 7019029 Differential & Case Assembly (Sold as an Assembly Only) 1
7019002 Pinion & Bearing Adjusting Shims Kit (Includes Items 4, 6, 11,
12 & 15) 1
7019018 Differential Adjusting Shims Kit (Includes Items 15 & 21) 1
