3120893 2-17
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
2000158 ENGINE COMPONENTS Ref. B
101 7017653 Carburetor W/Auto Choke 1
7017652 Rebuilt Kit - 7017653 Carburetor 1
7017641 Gasket - Air Intake to Carburetor 1
7017669 Elbow, Carburetor 1
101A 7017639 Solenoid, Fuel 1
101B 7017637 Switch, Choke 1
101C 7017638 Choke, Vacuum 1
102 7017620 Starter (Not Shown) 1
103 7017603 Dipstick 1
104 Use 7019932 Plug, Spark (was p/n 7017608) 3
105 7017600 Filter, Oil 1
106 7017606 Coil, Ignition 3
107 7017607 Boot, Spark Plug 3
108 Not Used
109 7017612 Gasket - Inlet (Not Shown) 1
110 7017613 Gasket - Outlet (Not Shown) 1
111 7017614 Gasket - Water Pump (Not Shown) 1
112 7017602 Tube, Dipstick 1
113 Not Used
114 7017663 Switch, Water Temperature 1
115 7017616 V-Belt 1
116 7017656 Filter, Fuel 1
117 Not Used
118 7017657 Pump, Fuel 1
119 7017621 Module, Ignition 1
120 7017622 Trigger, Ignition (Not Shown) 1
121 7017605 Cap, Oil Fill 1
122 7017604 Plug, Oil Drain (Used Before Code Date 98083100) 2
7017654 Plug, Oil Drain (Used After Code Date 98083100) 2
123 7017615 Pump, Water 1
124 7017611 Thermostat 1
125 7017609 Alternator 1
126 1660229 Coupling, Pump 1
127 7017667 Link, Governor 1
128 7017668 Spring, Link 1
129 7017659 Module, Electronic Ignition 1
130 7017655 Motor, Servo 1
131 7023362 Housing, Bell 1
132 7017646 Flywheel/Ring Gear Assembly (Not Shown) 1
133 7017670 Stud, Muffler Mount (Not Shown) 4
7017671 Nut, Muffler Mount (Not Shown) 4
134 7024414 Gasket, Muffler (Not Shown) 1
FIGURE 2-4. VANGUARD GAS ENGINE INSTALLATION (S/N 48113 TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
